Data

NVTreeView

NVTreeView XAML, every kit attribute, and what each attribute does. NVTreeView in the Data layer.

About

NVTreeView in the Data layer.

XAML with every attribute

Namespace xmlns:nv="http://nuvyntralabs.com/uikit". Kit attributes first, then inherited MAUI VisualElement / View members. Framework properties are the same on every NV* view and are not repeated in the official control reference.

xmlns:nv="http://nuvyntralabs.com/uikit"

<nv:NVTreeView
    Roots="{Binding Roots}"
    IsVisible="True"
    IsEnabled="True"
    Margin="0"
    HorizontalOptions="Fill"
    VerticalOptions="Fill"
    BindingContext="{Binding}" />

Attributes

custom names are Lumina API. Unmarked names match familiar MAUI / forms usage.

Attribute	Type	Default	Kind	Explanation
`Roots`	`IList<NVTreeNode>`	—	custom	`Title`, `IsExpanded`, `IsChecked`, `Children`

Inherited MAUI attributes

Every NV* view also inherits MAUI ContentView / VisualElement members. Those are framework properties.

Attribute	Type	Default	Explanation
`IsVisible`	`bool`	`true`	MAUI `VisualElement`. Hide the control without removing it from the tree.
`IsEnabled`	`bool`	`true`	MAUI `VisualElement`. When false, the control ignores input and uses the Disabled visual state.
`Margin`	`Thickness`	`0`	MAUI `View`. Outer gap around the control. Use `NVTokens.Space*` for Lumina rhythm.
`HorizontalOptions`	`LayoutOptions`	`Fill`	MAUI `View`. Horizontal alignment in the parent (`Start`, `Center`, `End`, `Fill`).
`VerticalOptions`	`LayoutOptions`	`Fill`	MAUI `View`. Vertical alignment in the parent.
`BindingContext`	`object?`	inherited	MAUI `BindableObject`. Source for `{Binding …}` paths on this subtree.

Typical usage

Short sample from the official control reference — not every attribute.

<nv:NVTreeView />
